Modular high-voltage storage system (LiFePO₄) with 4.8 kWh capacity – ideal for scalable energy storage solutions. Up to 16 modules can be connected in parallel to create almost unlimited storage systems (up to 76.8 kWh). Extremely durable with over 6,000 charge cycles at 95 % depth of discharge (DoD), high safety thanks to integrated BMS, and outstanding efficiency. Weight: approx. 39.7 kg. Ready for shipment within 24 hours after payment receipt.
Technical Specifications
-
Rated Voltage & Capacity: 48 V / 4.8 kWh (100 Ah), usable: approx. 4.56 kWh (95 % DoD)
-
Max. Charge/Discharge Current: recommended ~80 A, short-term up to ~100 A
-
Dimensions: approx. 442 × 420 × 161 mm (W × D × H)
-
Weight: approx. 39.7 kg
-
Lifespan & Cycle Durability: > 6,000 cycles at 90 % DoD, 10-year warranty
-
Communication: RS485 & CAN for system integration
-
Protection & Safety: BMS protection features: overcharge, deep discharge, overcurrent, over-/under-temperature; multiple certifications (TÜV, CE, UN38.3…)
-
Modular System Design: Up to 16 modules in a string; optional expansion via LV hub possible
Product Detail Block
-
Model: Pylontech US5000
-
Product Type: High-voltage LiFePO₄ storage module (4.8 kWh)
-
Material & Weight: Robust construction, approx. 39.7 kg net
-
Origin: Pylontech – renowned manufacturer of modular battery systems
-
Key Advantages:
– Highly scalable and long-term usable
– Extremely cycle-stable and efficient
– Compact, safe, and future-proof through modular networking
Modular high-voltage storage system (LiFePO₄) with 4.8 kWh capacity – ideal for scalable energy storage solutions. Up to 16 modules can be connected in parallel to create almost unlimited storage systems (up to 76.8 kWh). Extremely durable with over 6,000 charge cycles at 95 % depth of discharge (DoD), high safety thanks to integrated BMS, and outstanding efficiency. Weight: approx. 39.7 kg. Ready for shipment within 24 hours after payment receipt.
Technical Specifications
-
Rated Voltage & Capacity: 48 V / 4.8 kWh (100 Ah), usable: approx. 4.56 kWh (95 % DoD)
-
Max. Charge/Discharge Current: recommended ~80 A, short-term up to ~100 A
-
Dimensions: approx. 442 × 420 × 161 mm (W × D × H)
-
Weight: approx. 39.7 kg
-
Lifespan & Cycle Durability: > 6,000 cycles at 90 % DoD, 10-year warranty
-
Communication: RS485 & CAN for system integration
-
Protection & Safety: BMS protection features: overcharge, deep discharge, overcurrent, over-/under-temperature; multiple certifications (TÜV, CE, UN38.3…)
-
Modular System Design: Up to 16 modules in a string; optional expansion via LV hub possible
Product Detail Block
-
Model: Pylontech US5000
-
Product Type: High-voltage LiFePO₄ storage module (4.8 kWh)
-
Material & Weight: Robust construction, approx. 39.7 kg net
-
Origin: Pylontech – renowned manufacturer of modular battery systems
-
Key Advantages:
– Highly scalable and long-term usable
– Extremely cycle-stable and efficient
– Compact, safe, and future-proof through modular networking
