The MultiPlus‑II 48/5000/70-50 is an all-in-one hybrid inverter with charging and UPS capability, suitable for both off-grid and grid-tied systems. It combines reliable surge protection, adaptive PowerAssist support, and fast switching for critical loads. Integration with monitoring tools makes it ideal for professional and private PV storage solutions. Ready for dispatch within 24 hours after payment.
Technical Specifications
- DC Input Voltage: approx. 38–66 V (48 V battery system)
- Continuous Power (Inverter Mode): 5 000 VA (~4 000 W) at 25 °C
- Peak Power: up to 9 000 W
- Battery Charging: max. 70 A at 48 V
- Transfer Switch (AC Pass-Through): 50 A
- Efficiency: up to approx. 96 %
- Fast UPS Switching: <20 ms during power interruption
- PowerAssist & PowerControl: Boosts output during overloads and optimizes self-consumption
- Parallel / 3-Phase Capable: Combine multiple units for higher output or three-phase output
- Monitoring & Control: Integration with GX systems and remote access via VRM platform
- Operating Temperature: –40 °C to +65 °C (with fan cooling)
- Enclosure: Steel, blue (RAL 5012), IP22
- Dimensions: approx. 565 × 323 × 148 mm
- Weight: approx. 29 kg
Product Details
- Model: MultiPlus‑II 48/5000/70-50
- Product Type: Hybrid inverter with charger (Inverter + Charger)
- Material: Steel enclosure, IP22 protection, fan-cooled
- Weight: approx. 29 kg
- Origin: Victron Energy – reputable manufacturer of professional energy systems
-
Key Benefits:
- Powerful inverter + charger combination (5 kVA)
- UPS capability with fast switching (<20 ms)
- Overload support via PowerAssist
- Modular expansion (parallel / 3-phase connection)
- Remote control and monitoring via GX/VRM platform
